| Grade | M5 | M6 | F7 | F8 | F9 |
| Type | 2-components fabric with high efficiency & low resistance | ||||
| Color (Europe standard) | White | Green | Light Pink | Light Yellow | White |
| Efficiency (colorimetric method) | ≥45% | ≥65% | ≥85% | ≥95% | ≥98% |
| Weight (g/m²) | 175±5 | 185±5 | 210±5 | 225±5 | 240±5 |
| Thickness (mm) | 5±1 | 5±1 | 6±1 | 6±1 | 6±1 |
| Dust Holding Capacity (g) | 175 | 185 | 190 | 200 | 220 |
| Regular Size | W0.68*80 m (can be customized) | ||||
| Weight/roll | 11~15 kg | ||||
| Operating temperature | -10~90℃ | ||||
| Operating humidity | ≤80%RH | ||||
Our products include industrial pre-filter, pocket/bag air filter, HEPA filter, V-bank filter, chemical air filter; household air purifier replacement HEPA, carbon air filter and combination air filter, cabin air filter, cleaner air filter, humidifier air filter as well as air filter materials such as pocket filter roll media, paint stop fiberglass media, ceiling filter media, coarse filter media, melt-blown fabric, air filter paper, etc.
HVAC system, for pocket filter and panel filter materials as intermediate filtration or pre-filtration.
description2
The pocket filter media is made from high-quality PP (Polypropylene) and PET (Polyethylene Terephthalate) raw materials, ensuring they are safe, durable, and fully recyclable.
We supply pocket filter media in efficiency grades ranging from M5, M6, F7, F8, to F9, with corresponding colorimetric efficiencies from ≥45% up to ≥98% according to European standards.
Yes, our regular size is W0.68*80 m per roll, but the roll media can be easily cut to custom sizes and specifications based on the client's requirements.
The filter material is designed to operate safely within a temperature range of -10℃ to 90℃, and under relative humidity levels of ≤80%RH.
These materials are primarily used in HVAC systems, serving as intermediate filtration or pre-filtration media for pocket and panel filters.
The density of the filter material increases step by step, allowing it to capture particles throughout the depth of the media. This multi-layered design increases dust holding capacity and extends service life while maintaining low resistance.
